Detailed Description
Farm King 12 Wheel Vertical V Hay Rake
Trailing V rakes
Available in 12 and 14 wheel versions
Adjustable swath width
Adjustable hitch height
General Working width: TVR12: 326 inches TVR14: 369 inches
Swath width: (Adjusted on final wheel, angle measured from frame.) Center point: 75 degrees (same angle as other wheels) Rear point: 70 degrees Front point: 80 degrees
Transport Width: TVR12/TVR14: 107 inches
Transport Height: TVR12/TVR14: 73 inches
Unit Length: TVR12: 300 inches TVR14: 365 inches
Unit Weight: TVR12: 3450 LBS TVR14: 4280 LBS
Frame Dimensions: (Main and Wing) Tube: 5x5 inch (main frame) 11 gauge wall (rear cross frame) ¼ wall Gussets: ¼ inch material
Rake and Transport Wheels
Teeth Per Wheel: Both Versions: 40
Wheel Diameter: Both Versions: 60 inches
Tine Diameter: Both Versions: 7.5MM
Tine Hubs: serviceable double roller bearing
Main Wheel Hubs: CTD 5 bolt serviceable double roller bearing hubs
Transport Wheels: NTI ST205/75/R15
Number of Rake wheels: TVR 12: 12 TVR 14: 14
Number of transport wheels: TVR12: 4 (2 castors) TVR14: 6 (4 castors)
Tractor Requirements Horsepower: 40-60 Hydraulics: 2 remotes @ 1800 PSI
